Product Details:
|
| Type: | Crimp Terminal | Material: | Pure Copper |
|---|---|---|---|
| Certificate: | UL, Rosh, Reach, ISO | Surface Treatment: | Coated Tin |
| Application: | Wire Connecting | Special: | OEM Service Offered |
| Color: | Silver | Name: | China High Quality Cable Lug Price |
| High Light: | 1.5mm2 Copper Cable Terminal,630mm2 wire crimp connectors,630mm2 Copper Cable Terminal |
||
UL ISO Bell Mouth Tubular Copper Cable Terminal For Car
China High quality bell mouth cable lug price
Patent cable lug, China Brand name,Taiwanese mature technology, Top quality for long life time
1. Material: 100% Pure copper,Top material to producing out good quality products
2. Size: 1.5mm2~630mm2
3. Standard: JIS/DIN/Singapore/UK
4. Certification: UL, ISO9001, ROHS, Reach
| Product Name | China High quality cable lug price |
| Material | Pure copper |
| Color | Silver |
| Standard | JIS/DIN/Singapore/UK |
| Certification | UL, Rosh, Reach, ISO9001 |
| Used | Car, ship, telecommunication equipment, controller systerm, power cabinet |
| PART NO | TYPE | A | B | W | E | D | L | C |
| 03601 | 1.5-3 | 3.3 | 1.8 | 6.5 | 3.0 | 5.5 | 16.0 | 3.3 |
| 03602 | 1.5-4 | 4.5 | 17.0 | 4.4 | ||||
| 03603 | 1.5-5 | 7.5 | 19.0 | 5.3 | ||||
| 03604 | 2.5-3 | 4.2 | 2.3 | 7.5 | 5.0 | 6.0 | 16.0 | 3.3 |
| 03605 | 2.5-4 | 18.0 | 4.4 | |||||
| 03606 | 2.5-5 | 8.5 | 19.0 | 5.3 | ||||
| 03607 | 2.5-6 | 9.0 | 6.0 | 6.4 | ||||
| 03607 | 4-4 | 5.0 | 3.0 | 8.5 | 6.0 | 6.5 | 21.0 | 4.4 |
| 03608 | 4-5 | 9.0 | 6.0 | 22.0 | 5.3 | |||
| 03609 | 4-6 | 10.0 | 7.0 | 23.0 | 6.4 | |||
| 03610 | 6-5 | 6.0 | 4.0 | 9.5 | 6.0 | 6.5 | 22.0 | 5.3 |
| 03611 | 6-6 | 10.0 | 7.0 | 23.0 | 6.4 | |||
| 03612 | 6-8 | 13.6 | 10.0 | 30.0 | 8.4 | |||
| 03613 | 10-5 | 6.9 | 4.4 | 10.5 | 5.9 | 9.0 | 27.0 | 5.4 |
| 03614 | 10-6 | 6.4 | ||||||
| 03615 | 10-8 | 14.0 | 9.7 | 10.0 | 35.0 | 8.4 | ||
| 03616 | 10-10 | 16.0 | 12.0 | 39.0 | 10.5 | |||
| 03617 | 10-12 | 18.0 | 12.5 | |||||
| 03618 | 16-5 | 8.0 | 5.6 | 11.0 | 5.9 | 11.0 | 29.5 | 5.4 |
| 03619 | 16-6 | 6.4 | ||||||
| 03620 | 16-8 | 14.0 | 9.7 | 38.0 | 8.4 | |||
| 03621 | 16-10 | 16.0 | 12.0 | 42.0 | 10.5 | |||
| 03622 | 16-12 | 18.0 | 12.5 | |||||
| 03623 | 25-5 | 9.5 | 7.0 | 13.5 | 9.7 | 10.0 | 40 | 5.4 |
| 03624 | 25-6 | 6.4 | ||||||
| 03625 | 25-8 | 8.4 | ||||||
| 03626 | 25-10 | 16.8 | 12.0 | 43.5 | 10.5 | |||
| 03627 | 25-12 | 18.0 | 12.7 | |||||
| 03628 | 35-5 | 11.0 | 8.2 | 15.5 | 9.7 | 14.0 | 41.0 | 5.4 |
| 03629 | 35-6 | 6.4 | ||||||
| 03630 | 35-8 | 8.5 | ||||||
| 03631 | 35-10 | 12.0 | 45.0 | 10.5 | ||||
| 03632 | 35-12 | 18.0 | 13.0 | |||||
| 03633 | 35-14 | 20.0 | 15.0 | 50.0 | 14.7 |
FAQ
Q1: Are you trading company or manufacturer ?
A: We are directly factory, there is not any trading company between us, help you save much cost
Q2: How can you proof of pure copper?
1: we provide free sample to test
2: we provide third party material analasys report for your check
3: Your are allowed to arrange third party to inspect us freely
Q3: How long is your delivery time?
A: Generally it is 5 working days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q4: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q5: What is your terms of payment ?
A: T/T for large order and western union for sample order
